CZI LP35 Searchlight And Broadcasting System For DJI M350RTK Drone


1. LP35 searchlight broadcasting all-in-one machine, rated power up to 90W, compatible with DJI M350RTK drone through OSDK interface.
2. LP35 can emit a 13-degree sharp beam with uniform brightness. At an illumination height of 150m, the central illumination reaches 6.3lux, and the effective searchlight area reaches 917 square meters.
3. The loudspeaker has strong sound penetration, the maximum sound pressure can reach 126dB, the effective sound distance is 400 meters, supports real-time shouting, TTS, and other functions, and is easy and fast to operate.
4. Built-in red and blue flashing warning lights effectively improve the recognition of the drone, and can be linked with the gimbal camera to perfectly cooperate with the camera operation.

Parameters:
1. Electrical interface: DJI OSDK
2. Weight: less than or equal to 550g
3. Dimensions: L235mmxW220mmxH85mm
4. Power: 96W (maximum)
5. Bluetooth protocol: Bluetooth v4.2 BR&EDR and Bluetooth Low Energy
6. Bluetooth operating frequency band: 2400?2483.5MHz
7. Warning light mode: red and blue flashing, red flashing, blue flashing
8. Warning light visible distance: 200m
9. Megaphone sound pressure: 126dB at 1m
10. Megaphone maximum power: 30W
11. Effective broadcast distance: 400m
12. Broadcast mode: / real-time shouting/recording upload/audio file playback (audio format MP3) / text-to-speech playback (support text recording)
13. Searchlight light flux: 6000+/-3%lm
14. Searchlight FOV: 13 degrees
15. Center illumination: 6.3Lux/14.4Lux/57Lux
16. Searchlight distance: 150m/100m/50m
17. Spot diameter: 34m/22.8m/11.4m
18. Searchlight area: 917 square meters/407 square meters/102 square meters
19. Searchlight LED power: 60W
20. Gimbal control rotation range: pitch +55~-65 degrees; horizontal +/-35 degrees; roll +/-25 degrees
21. Searchlight function: constant light mode/strobe mode/brightness adjustment/gimbal angle adjustment/
22. Automatically follow the camera/AI spot centering
23. Drone platform support: M350
24. Support APP: CZI Pilot, DJI Pilot, CZI Audio (Android), CZI Assistant (PC)


Specification:
Package Weight
One Package Weight 2.90kgs / 6.40lb
One Package Size 25cm * 35cm * 38cm / 9.84inch * 13.78inch * 14.96inch
Qty per Carton 1
Carton Weight 2.90kgs / 6.39lb
Carton Size 25cm * 35cm * 38cm / 9.84inch * 13.78inch * 14.96inch
Loading Container 20GP: 802 cartons * 1 pcs = 802 pcs
40HQ: 1861 cartons * 1 pcs = 1861 pcs

CZI LP35 Searchlight And Broadcasting System For DJI M350RTK Drone

Product form

SKU: TBD06053912

  • In stock (Processing Time 1 - 72 hours)

€3.762,98

    • Guaranteed secure & safe checkout.

    Icon for truckShipping Methods

    To find out all available shipping methods, and the exact delivery time add the product to the cart and verify it using our shipping calculator.

    Icon for 24_hour_clockOrder Processing Time

    All orders are shipped within a maximum of 72 hours from the order's arrival.

    Icon for coinMoney Back Guarantee

    Garmade Money Back Guarantee- Get the item you ordered or your money back, it's that simple.

    Icon for image_placeholderMismatched Product

    Product doesn't match the description? Contact us within 31 days after you receive it!

    Icon for mobile_paymentRefunds

    In case of cancellation, money will be refunded to your account within 14 days.

    Description


    1. LP35 searchlight broadcasting all-in-one machine, rated power up to 90W, compatible with DJI M350RTK drone through OSDK interface.
    2. LP35 can emit a 13-degree sharp beam with uniform brightness. At an illumination height of 150m, the central illumination reaches 6.3lux, and the effective searchlight area reaches 917 square meters.
    3. The loudspeaker has strong sound penetration, the maximum sound pressure can reach 126dB, the effective sound distance is 400 meters, supports real-time shouting, TTS, and other functions, and is easy and fast to operate.
    4. Built-in red and blue flashing warning lights effectively improve the recognition of the drone, and can be linked with the gimbal camera to perfectly cooperate with the camera operation.

    Parameters:
    1. Electrical interface: DJI OSDK
    2. Weight: less than or equal to 550g
    3. Dimensions: L235mmxW220mmxH85mm
    4. Power: 96W (maximum)
    5. Bluetooth protocol: Bluetooth v4.2 BR&EDR and Bluetooth Low Energy
    6. Bluetooth operating frequency band: 2400?2483.5MHz
    7. Warning light mode: red and blue flashing, red flashing, blue flashing
    8. Warning light visible distance: 200m
    9. Megaphone sound pressure: 126dB at 1m
    10. Megaphone maximum power: 30W
    11. Effective broadcast distance: 400m
    12. Broadcast mode: / real-time shouting/recording upload/audio file playback (audio format MP3) / text-to-speech playback (support text recording)
    13. Searchlight light flux: 6000+/-3%lm
    14. Searchlight FOV: 13 degrees
    15. Center illumination: 6.3Lux/14.4Lux/57Lux
    16. Searchlight distance: 150m/100m/50m
    17. Spot diameter: 34m/22.8m/11.4m
    18. Searchlight area: 917 square meters/407 square meters/102 square meters
    19. Searchlight LED power: 60W
    20. Gimbal control rotation range: pitch +55~-65 degrees; horizontal +/-35 degrees; roll +/-25 degrees
    21. Searchlight function: constant light mode/strobe mode/brightness adjustment/gimbal angle adjustment/
    22. Automatically follow the camera/AI spot centering
    23. Drone platform support: M350
    24. Support APP: CZI Pilot, DJI Pilot, CZI Audio (Android), CZI Assistant (PC)


    Specification:
    Package Weight
    One Package Weight 2.90kgs / 6.40lb
    One Package Size 25cm * 35cm * 38cm / 9.84inch * 13.78inch * 14.96inch
    Qty per Carton 1
    Carton Weight 2.90kgs / 6.39lb
    Carton Size 25cm * 35cm * 38cm / 9.84inch * 13.78inch * 14.96inch
    Loading Container 20GP: 802 cartons * 1 pcs = 802 pcs
    40HQ: 1861 cartons * 1 pcs = 1861 pcs
