Mobile Phones Full Protocol Fast Charging Module Fast Charging Motherboard For Huawei SCP / FCP(3516)


1. Compact in size, easy to carry
2. Widely applicable, can be used daily for fast charging of mobile phones, and can also be powered by batteries, solar panels, DC generators, etc
3. Wide power supply voltage range: 6 to 35V. The input voltage should be higher than the required output voltage
4. High-performance input anti-reverse connection. A dedicated MOS transistor is used for anti-reverse connection to prevent damage from reverse connection
5. Equipped with a fast charging status indicator light. The blue light indicates the output, and the red light indicates the fast charging status
6. Dual parallel low-resistance electrolytic capacitors + 6 1206 ceramic capacitors, with better performance
7. Supports fast charging protocols: USN PD3.0 (PPS); For Qualcomm QC4+/QC3.0; For Huawei SCP/FCP; For iOS 2.4A; For Samsung AFC; For vivo 9V 2A dual engines; For MediaTek PE2.0; For OPPO VOOC (only 3518 supports); For OnePlus DASH (only 3518 supports)

Notes for attention
1. For low-voltage high-current fast charging, please use the original data cable. If you want to measure the charging voltage and current, you must use a USB meter with low internal resistance; otherwise, it will affect the charging current
2. The Type-C port is used for output charging. It can be used in combination with C-To-C/Type-C male-to-male dual-head data cable to charge mobile phones or laptops
3. OPPO and OnePlus phones should use the USB port (3518) for charging. For charging protocols such as QC4+/QC4.0/PD3.0, the Type-C port should be used
4. When the supply voltage is higher than 21V, the PD protocol of the C port can support a maximum output of 20V 3A. The module is small and should be well ventilated and cooled when used with a laptop that supports PD charging
5. When both the USB port and the Type-C port are plugged into the phone at the same time, both ports will output 5V


Specification:
Package Weight
One Package Weight 0.03kgs / 0.06lb
One Package Size 9cm * 5cm * 4cm / 3.54inch * 1.97inch * 1.57inch
Qty per Carton 288
Carton Weight 9.00kgs / 19.84lb
Carton Size 50cm * 38cm * 32cm / 19.69inch * 14.96inch * 12.6inch
Loading Container 20GP: 438 cartons * 288 pcs = 126144 pcs
40HQ: 1018 cartons * 288 pcs = 293184 pcs

Mobile Phones Full Protocol Fast Charging Module Fast Charging Motherboard For Huawei SCP / FCP(3516)

Product form

SKU: TBD0606746901A

  • In stock (Processing Time 1 - 72 hours)

€8,07

    • Guaranteed secure & safe checkout.

    Icon for truckShipping Methods

    To find out all available shipping methods, and the exact delivery time add the product to the cart and verify it using our shipping calculator.

    Icon for 24_hour_clockOrder Processing Time

    All orders are shipped within a maximum of 72 hours from the order's arrival.

    Icon for coinMoney Back Guarantee

    Garmade Money Back Guarantee- Get the item you ordered or your money back, it's that simple.

    Icon for image_placeholderMismatched Product

    Product doesn't match the description? Contact us within 31 days after you receive it!

    Icon for mobile_paymentRefunds

    In case of cancellation, money will be refunded to your account within 14 days.

    Description


    1. Compact in size, easy to carry
    2. Widely applicable, can be used daily for fast charging of mobile phones, and can also be powered by batteries, solar panels, DC generators, etc
    3. Wide power supply voltage range: 6 to 35V. The input voltage should be higher than the required output voltage
    4. High-performance input anti-reverse connection. A dedicated MOS transistor is used for anti-reverse connection to prevent damage from reverse connection
    5. Equipped with a fast charging status indicator light. The blue light indicates the output, and the red light indicates the fast charging status
    6. Dual parallel low-resistance electrolytic capacitors + 6 1206 ceramic capacitors, with better performance
    7. Supports fast charging protocols: USN PD3.0 (PPS); For Qualcomm QC4+/QC3.0; For Huawei SCP/FCP; For iOS 2.4A; For Samsung AFC; For vivo 9V 2A dual engines; For MediaTek PE2.0; For OPPO VOOC (only 3518 supports); For OnePlus DASH (only 3518 supports)

    Notes for attention
    1. For low-voltage high-current fast charging, please use the original data cable. If you want to measure the charging voltage and current, you must use a USB meter with low internal resistance; otherwise, it will affect the charging current
    2. The Type-C port is used for output charging. It can be used in combination with C-To-C/Type-C male-to-male dual-head data cable to charge mobile phones or laptops
    3. OPPO and OnePlus phones should use the USB port (3518) for charging. For charging protocols such as QC4+/QC4.0/PD3.0, the Type-C port should be used
    4. When the supply voltage is higher than 21V, the PD protocol of the C port can support a maximum output of 20V 3A. The module is small and should be well ventilated and cooled when used with a laptop that supports PD charging
    5. When both the USB port and the Type-C port are plugged into the phone at the same time, both ports will output 5V


    Specification:
    Package Weight
    One Package Weight 0.03kgs / 0.06lb
    One Package Size 9cm * 5cm * 4cm / 3.54inch * 1.97inch * 1.57inch
    Qty per Carton 288
    Carton Weight 9.00kgs / 19.84lb
    Carton Size 50cm * 38cm * 32cm / 19.69inch * 14.96inch * 12.6inch
    Loading Container 20GP: 438 cartons * 288 pcs = 126144 pcs
    40HQ: 1018 cartons * 288 pcs = 293184 pcs
